WX-600D
WANXU
The double shaft shredder with recycling control system allows for efficient waste processing, transforming bulky industrial scrap into manageable, uniform fragments. It is designed for efficient shredding of a wide range of recyclable materials, providing a reliable size-reduction solution for heavy-duty material recovery facilities. The machine features a double shaft design for precise and efficient cutting, generating a distinct, powerful crushing force that grips and pulls materials downward through the interlocking blades. Its compact size makes it suitable for a wide range of industrial applications, allowing facility managers to integrate it smoothly into existing processing lines without requiring extensive spatial modifications.
Built with a heavy steel frame, the equipment absorbs the intense vibrations during operation, ensuring stable performance even when processing dense metallic components. The intelligent control panel constantly monitors the load, automatically reversing the shafts if a jam is detected to protect the mechanical integrity of the system.
Parameter | Value |
Model | WX-600D / WX-600D+ |
Motor | 25kW / 25kW-2 |
Reducer | JK77 / JK77-2 |
Electric Cabinet | PLC Controller |
Input Speed | 16 turns/min |
Blade Size | Dia 180 mm |
Shaft Size | Dia 80 mm |
Dimension | 2000×1000×1530 mm (WX-600D) / 2500×1200×1530 mm (WX-600D+) |
This industrial reduction equipment is engineered to handle complex, bulky waste streams, delivering consistent output standards that facilitate easier transportation and secondary processing.
Capable of crushing solid materials such as plastics, rubber, fiber, paper, wood, electronics and cables. In practical scenarios, it easily processes scrap tires, large-diameter metal drums, automotive bumpers, and complex electronic circuit boards, reducing them into uniform, manageable pieces.
Consists of crushing blade group, bearing box, frame, feed system, power system and electrical control system. This structural design prevents material wrap-around and ensures continuous operation without frequent manual intervention.
Ideal for industries that handle difficult to crush materials. Whether dealing with municipal solid waste, industrial manufacturing scrap, or end-of-life vehicle components, the equipment provides a targeted solution that maximizes volume reduction.
Rugged design for long-term use in heavy-duty applications. The reinforced housing and specialized shock-absorbing mounts protect internal components from the continuous impact generated during the shredding cycle.
The shredder is suitable for a wide range of solid materials, including plastics, rubber, fiber, paper, wood, electronic components, and cables. It effectively breaks down these diverse inputs into consistent sizes, preparing them for the next stage of resource recovery.
The shredder is driven by a 3kW motor, and depending on the model, a dual motor setting is available. This configuration provides the necessary rotational force to shear through dense materials without stalling.
The input speed for both the WX-600D and WX-600D+ models is 16 rpm. This slow-speed, high-torque operation ensures that materials are gripped securely and torn apart with maximum efficiency while minimizing noise and dust generation.
The blade diameter for both models is 180mm, and the shaft diameter is 80mm. These precise dimensions allow for optimal bite angles and sufficient clearance to process bulky items without clogging the cutting chamber.
The shredder can efficiently process a wide range of materials, achieving high throughput, low power consumption, and high torque output. This balance allows facilities to maintain continuous processing lines without excessive energy expenditures.
The material shredding rate of the machine is as high as approximately 95%, and the recycling efficiency is extremely high. This means less material requires secondary passes, significantly improving overall facility throughput.
Observing the equipment in a real industrial environment reveals its true operational stability. Live processing demonstrations highlight the smooth feeding mechanism and the relentless high-torque crushing process that easily digests irregular shapes.
Achieves a material shredding rate of approximately 95%. The precise interlocking of the cutting discs ensures that waste is thoroughly reduced in a single pass, yielding uniform output sizes that optimize downstream sorting and melting processes.
Utilizes a heavy-duty hardened surface reducer and YF-3 motor. This power transmission setup minimizes energy loss between the motor and the cutting shafts, translating electrical power directly into raw shearing force.
Equipped with advanced dust removal equipment for 99% dust control. By capturing airborne particulates directly at the crushing zone, it maintains a cleaner processing environment and protects operators from respiratory hazards.
Made from H13 and SKD-11, ensuring excellent wear resistance. These alloy steels are heat-treated to maintain sharp cutting edges even after prolonged exposure to abrasive metals, stones, and hardened plastics.
Beyond the equipment itself, successful waste reduction relies on extensive manufacturing capabilities and ongoing technical support. Our production facilities are equipped with multiple advanced manufacturing lines, backed by years of experience in fabricating heavy-duty recycling machinery. We provide end-to-end turnkey solutions, ensuring that the shredder integrates flawlessly into your broader material recovery facility.
Every unit undergoes rigorous factory testing under simulated harsh conditions before dispatch. Our quality control system monitors every stage of production—from raw steel inspection to final motor alignment—guaranteeing a 100% pass rate. This meticulous attention to detail ensures the equipment performs reliably in the most demanding industrial environments.
Supported by a dedicated research and development team, we offer tailored configurations to meet specific operational demands. Whether your facility requires specialized dual-motor setups for extra torque, custom blade materials for highly abrasive scrap, or uniquely designed feed hoppers for oversized items, our engineering team can adapt the core design to fit your exact material profile.
Procuring heavy machinery requires confidence in long-term maintenance. Our international service team provides comprehensive support, including detailed installation guidance, on-site or remote commissioning, and a reliable supply chain for replacement parts. This proactive approach minimizes downtime and helps facility operators maintain peak processing efficiency year after year.
